CAMTEC

CPS-EX-series

DIN rail charging rectifier & industrial power supply

Performance Features
Models
Downloads

Performance Features

Optional LAN interface Plug & Play
3D heat dissipation
Real-time I/V programming
Real-time I/V monitoring
Reference voltage for autonomous programming
CSB Current Share Bus parallel operation of 7 units
Lock function for secure locking
Remote shutdown
Sense mode
Power Good relay DC-ok
Precise dynamics during load changes
Series and parallel operation up to 100kW
EMC conducted Class B, radiated Class A
Efficiency 92-94%
PFC power factor 0.99
Variably controlled fans from Papst
Long service life under heavy use
Solid 2U and 3U subframes available

Models

To product comparison

Model

Watchlist

Comparison

Voltage

Current

Power

Input

Output

Control mode

Function

Quadrants

Standard interface

Operating modes

Cooling

CPS-EX3000.012(R2) - 2 - 15 VDC / 100 - 200 A / 2400 W CT1255A

200

3.000

CC/CV

Quelle u/o Senke

Q1 (U+,I+)

Analog

Luft

Options

Article number	Description	Watchlist	Comparison
41858	CPS-LAN - Ethernet Interface DIGI3201	CPS-LAN - Ethernet Interface DIGI3201	CPS-LAN - Ethernet Interface DIGI3201

CPS-EX2000.024(R2) - 24 - 30 VDC / 42 - 84 A / 2000 W CT1250A

2.000

CC/CV

Quelle u/o Senke

Q1 (U+,I+)

Analog

Luft

Options

Article number	Description	Watchlist	Comparison
41858	CPS-LAN - Ethernet Interface DIGI3201	CPS-LAN - Ethernet Interface DIGI3201	CPS-LAN - Ethernet Interface DIGI3201

CPS-EX3000.024(R2) - 24 - 30 VDC / 62,5 - 125 A / 3000 W CT1256A

125

3.000

CC/CV

Quelle u/o Senke

Q1 (U+,I+)

Analog

Luft

Options

Article number	Description	Watchlist	Comparison
41858	CPS-LAN - Ethernet Interface DIGI3201	CPS-LAN - Ethernet Interface DIGI3201	CPS-LAN - Ethernet Interface DIGI3201

CPS-EX2000.036(R2) - 30 - 45 VDC / 28 - 56 A / 2000 W CT1251A

2.000

CC/CV

Quelle u/o Senke

Q1 (U+,I+)

Analog

Luft

Options

Article number	Description	Watchlist	Comparison
41858	CPS-LAN - Ethernet Interface DIGI3201	CPS-LAN - Ethernet Interface DIGI3201	CPS-LAN - Ethernet Interface DIGI3201

CPS-EX3000.036(R2) - 30 - 45 VDC / 41,5 - 83 A / 3000 W CT1257A

3.000

CC/CV

Quelle u/o Senke

Q1 (U+,I+)

Analog

Luft

Options

Article number	Description	Watchlist	Comparison
41858	CPS-LAN - Ethernet Interface DIGI3201	CPS-LAN - Ethernet Interface DIGI3201	CPS-LAN - Ethernet Interface DIGI3201

CPS-EX2000.048(R2) - 45 - 58 VDC / 21 - 42 A / 2000 W CT1252A

2.000

CC/CV

Quelle u/o Senke

Q1 (U+,I+)

Analog

Luft

Options

Article number	Description	Watchlist	Comparison
41858	CPS-LAN - Ethernet Interface DIGI3201	CPS-LAN - Ethernet Interface DIGI3201	CPS-LAN - Ethernet Interface DIGI3201

CPS-EX3000.048(R2) - 45 - 58 VDC / 31,2 - 62,5 A / 3000 W CT1258A

62,5

3.000

CC/CV

Quelle u/o Senke

Q1 (U+,I+)

Analog

Luft

Options

Article number	Description	Watchlist	Comparison
41858	CPS-LAN - Ethernet Interface DIGI3201	CPS-LAN - Ethernet Interface DIGI3201	CPS-LAN - Ethernet Interface DIGI3201

CPS-EX2000.072(R2) - 58 - 90 VDC / 14 - 28 A / 2000 W CT1253A

2.000

CC/CV

Quelle u/o Senke

Q1 (U+,I+)

Analog

Luft

Options

Article number	Description	Watchlist	Comparison
41858	CPS-LAN - Ethernet Interface DIGI3201	CPS-LAN - Ethernet Interface DIGI3201	CPS-LAN - Ethernet Interface DIGI3201

CPS-EX3000.072(R2) - 58 - 90 VDC / 20,8 - 41,6 A / 3000 W CT1259A

41,6

3.000

CC/CV

Quelle u/o Senke

Q1 (U+,I+)

Analog

Luft

Options

Article number	Description	Watchlist	Comparison
41858	CPS-LAN - Ethernet Interface DIGI3201	CPS-LAN - Ethernet Interface DIGI3201	CPS-LAN - Ethernet Interface DIGI3201

CPS-EX2000.110(R2) - 90 - 150 VDC / 9,1 - 18,2 A / 2000 W CT1254A

150

18,2

2.000

CC/CV

Quelle u/o Senke

Q1 (U+,I+)

Analog

Luft

Options

Article number	Description	Watchlist	Comparison
41858	CPS-LAN - Ethernet Interface DIGI3201	CPS-LAN - Ethernet Interface DIGI3201	CPS-LAN - Ethernet Interface DIGI3201

Downloads

Datasheets	Type/Format
Datenblatt CPS-EX2000	PDF	CPS-EX2000_R2_D_E.pdf
Datenblatt CPS-EX3000	PDF	CPS-EX3000_R2_D_E.pdf
