Delta Elektronika
ES150-Serie
ES series 150 W
The ES300 series offers outstanding durability and stability.
Performance Features
- Very low output ripple and spikes
- EMC surpasses CE requirements: low emission & high immunity
- High programming speed
- Excellent dynamic response to load changes
- Protected against all overload and short circuit conditions
- Designed for long life at full power
- Master/Slave parallel and series operation with voltage and current sharing
- Voltage and current control with 10-turn potentiometers
- For laboratory use or optional 19” rack mounting
- Input voltage (single phase): 92-265 VAC (48-62 Hz)
- Active Power Factor Correction (PFC): 0.99 / 0.96 (at 100% load)
- Efficiency: up to 86% (at full load)
- Output ripple and spikes: 5 mVRMS / 15 VPP
- Regulation: 10 mV (0-100% load step)
- Recovery time: 50 µs (50-100% load step)
- Programming speed: 0.8 ms (10-90%)
- Analog programming accuracy: 0.2%
- Output voltage and current stability: 30.10-5 / 10.10-4
- MTBF: 500 000 hrs
- Operating ambient temperature: -20 to +50 ºC
- Width: half 19 inch
- Height: 66 mm (incl. feet)
- Depth: 333 mm
- Weight: 3.1 kg
Downloads
| Datasheets | Type/Format | ||
|---|---|---|---|
| Datenblatt ES150-Serie | ES150_D_E.pdf | ||
| Datenblatt Zubehör PSC-ETH 2 | PSC-ETH-2_D_E.pdf | ||
| Datenblatt Zubehör Delta RS232 | PSC232-488_D_E_2024_06_28.pdf |
