Lumina Power

LDP-Serie

Laser pulse/CW driver

The LDP pulsed laser diode drivers are the second generation of precision pulsed diode drivers offered by Lumina Power. Building on more than a decade of experience in laser diode driver technology the new LDP drivers are capable of outputting up to 400 amps. Pulse widths of 50µs through CW operation are now possible at rep-rates to 5kHz (higher Reprates Optional). The LDP incorporates new technology that enhances pulsed performance while reducing circuit complexity, shrinking the size of the package and increases reliability.

Performance Features
Models
Downloads

Performance Features

Power up to 2,000 W avg.
Peak up to 4 kW/400A
Up to 300 J/pulse
Rise time typically 10 µs
Also ideal as a pure CW driver with fast rise times
Additional auxiliary voltage ± 15 V, 200 mA
Analog interface with 0-10 V
PL e/SIL 3 Safety shutdown of the output optional

Models

To product comparison

Model	Watchlist	Comparison	Voltage	Current	Power	Input	Output	Control mode	Function	Quadrants	Standard interface	Operating modes	Cooling
LDP-1000-xxx-yyy-zzz ReferenzLP9131	LDP-1000-xxx-yyy-zzz Referenz	Comparison model description	200	400	1.000	AC	DC	CC	Leistungspulser	Q1 (U+,I+)	Analog	CW / High Speed / QCW	Luft
LDP-2000-xxx-yyy-zzz ReferenzLP9132	LDP-2000-xxx-yyy-zzz Referenz	Comparison model description	200	400	2.000	AC	DC	CC	Leistungspulser	Q1 (U+,I+)	Analog	CW / High Speed / QCW	Luft

Downloads

Datasheets	Type/Format
Datenblatt LDP-Serie	PDF	LDP_D_E.pdf
