Delta Elektronika
SM800-series
800 watt DC-Power Supply
The SM800 series consists of power supplies with excellent lifetime and stability.
Performance Features
- Designed for long life at full power
- Excellent dynamic response to load changes
- Protected against all overload and short circuit conditions
- EMC surpasses CE requirements: low emission & high immunity
- Low audible noise: fan is temperature controlled
- Master/Slave parallel and series operation with voltage and current sharing
- Stacking is allowed, space between units is not required
- Laboratory use (feet included), 19” rack mounting optional
- Remote sensing
- Interlock
- Input voltage (single phase): 90-265 VAC (48-62 Hz)
- Active Power Factor Correction (PFC): 0.99 (at 100% load)
- Efficiency: up to 89% (at full load)
- Output ripple and spikes: from 2 mVRMS / 8 mVPP
- Regulation: from 0.2 mV (0-100% load step)
- Recovery time: from 100 µs (50-100% load step)
- Programming speed: from 4 ms (10-90%), optional from 0.2 ms
- Analog programming accuracy: from 0.2%
- Output voltage and current stability: 6.10-5 / 9.10-5
- MTBF: 500 000 hrs
- Operating ambient temperature: -20 to +50 ºC
- Width: half 19 inch
- Height: 2 U
- Depth: 406 mm
- Weight: 5.4 kg
Downloads
| Datasheets | Type/Format | ||
|---|---|---|---|
| Datenblatt SM800-Serie | SM800_D_E.pdf | ||
| Datenblatt Zubehör PSC-ETH 2 | PSC-ETH-2_D_E.pdf | ||
| Datenblatt Zubehör Delta RS232 | PSC232-488_D_E_2024_06_28.pdf | ||
| Datenblatt Zubehör ISO AMP CARD/Modul (0-5V/0-10V) | ISO-AMP_D_E.pdf | ||
| Datenblatt Zubehör PSC232_intern | PSC232_D_E.pdf | ||
| Datenblatt Zubehör Highspeed Delta Elektronika | HighSpeed_D_E.pdf | ||
| Datenblatt Zubehör SM800 Powersink | SM800-PowerSink_D_E.pdf |
